CE Certificate Automatic Grinder For PCD / PCBN Tools grinding process

ZT-180 Type CNC Grinder is mainly used for grinding multiple cutters and parts such as artificial diamond, cubic boron nitride and hard alloy etc. The machine tool has sufficient rigidity and precision, which can realize constant pressure grinding and satisfy the grinding of high-precision and high-finish cutters to obtain the good grinding result.

Design Features:

1, Average 18 months natural ageing;
2, Adopt SCHNEEBERGER heavy duty and precision linear slide

3, 5-Axises NC and 2 linked machine.
4, Swing mechanism utilizing ball-screw by a servo motor
5,Japan SMC pneumatic system
6, Linear grating and angle encoder of this model is FAGOR
7, Camera with LCD monitor ,real-time online monitoring
8, Optical system for adjustable from 7-45 magnification even 0.05 radius can be grinded and inspected.

Technical Parameters

Attention:

1.When inject the oil into the tank, press the upper limit position indicator to avoid excessive injection.

2.Use the fresh oil. (Kerosene, gasoline, water and other liquids are prohibitive.)

3.Don’t use the mix oil for the different grades, otherwise the precipitate will be produced, mechanical failure will be occurred.

4.The broken inlet filter or removed will bring the dirt into the tank, mechanical failure will happen during the operation.

5.Lubrication pump use the rubber and plastic products, or other non-metallic material, don’t use the corrosive oil to prevent corrosion damage.

6.Keep the same power supply with the product description.

7.Make sure the worm is running after turning on the power supply.

8.In order to exclude the air and dust in the tube, pull the handle limit wheel and fill-in all the lubricant after the piping system matching.

9.Without oil in the tank, mechanical failure will happen after the long idling, and make the parts broken.

10.Must be grounded during installation.

11.Don’t push the limit wheel handle from the top to down.

12.Maintenace is available for the regular work.
